16 Bit Outdoor Video Screen IP65 High Brightness LED Display For
Advertising
Quick Detail:
1. Super brightness: >7000cd/㎡,
2. Support any format of video,Support any format of
video,RF,S-Video,
RGB,RGBHV,YUV,YC,COMPOSITION
3. Color and brightness simultaneously adjusted, vivid and high
definition images.
4. CE, RoHS qualified.
5. Longer lifespan. (more than 100,000 hours life)
Description:
1. This screen has built-in magnet-mount mechanism which can be
mounted on wall without punching or drilling the building
2. No need to alter the building structure. No air conditioner and
fan.
3. No frame structure required, light load for the wall
4. Quick maintenance / Save time and labor
Applications:
Commercial advertising: Square, Road side, High way, Airport,
Wharf, Hotel, Restaurant etc
Our Advantage:
Excellent video quality
Clear resolution
Stable performance
Specifications:
| Model No. | Smart 9 |
| Pixel Pitch | 9.375mm |
| Module Size | 300*300mm |
| Module Resolution(pixels) | 32*32 |
| Panel Size | 1200mm×2100mm, be customized as per customer's request. Max can be
1200*6000m |
| Panel Resolution(pixels) | 128×224 |
| Pixel Configuration(RGB) | 1R1G1B |
| Pixel Density(pixels/m2) | 11264 |
| Brightness(cd/m2) | 2000/7000 |
| Best Viewing Distance(m) | >9m |
| Max.Power Consumption(W/m2) | 440 |
| Waterproof Level | Indoor IP43/Indoor IP54/Outdoor IP65 |
| Wavelength | R 625±5nm, G 525±5nm B 470±5nm |
| LED SPEC | SMD3528/SMD3535 |
| Viewing Angle | 110°(H)/110°(V) |
| Operating Temperature | –20~50°C |
| Video Frame Rate(Hz) | 30-120HZ |
| Display Refresh Rate(Hz) | ≥16000HZ |
| Grey Level(colors) | 16.7million |
| MTBF | ≥50000 hours |
| Lifespan | ≥100000Hours |
| Working Voltage | DC24V |
| Drive Mode | Scan 1/4 |
| Graphics Card | DVI Graphics card |
| Video Signal | RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
| Control System | Dbstar |
| Software | Xmplayer 3.1 |
| Installation | Wall mount, hung |
Package:
Flight case and Fumigation-Free wooden case
